Horizontal resultant is 100−100cos 45°=29.289 N and vertical resultant 100sin 45°=70.711 N. Magnitude is√(29.289²+70.711²)=76.537 N. Divide by 10 kg to get 7.6537 m/s², or 7.65. The sketch represents the stated in-plane forces.
