GATE 2026 PI – Question 50

Industrial Engineering · Work System Design · 2 marks · Multiple select

The two-hand operation chart shown describes nut-and-bolt assembly by a left-handed operator. Which ONE OR MORE statements are correct?

Diagram for GATE 2026 PI question 50
  1. Work distribution between the hands is not balanced.
  2. The hands do not follow opposite motions.
  3. Work is well distributed between the hands.
  4. The dominant hand performs most tasks.

Practise this question in The GATE Grind →

Show answer and explanation

Correct answer: (A) Work distribution between the hands is not balanced.; (B) The hands do not follow opposite motions.

Explanation

The left hand is idle or holds the bolt during many right-hand operations. The right hand fetches, picks, transfers, assembles and releases items. Thus the load is unbalanced and the motions are not coordinated as opposite simultaneous movements. Since the operator is left-handed, the dominant hand is not the one doing most tasks. **A,B**.
